Product Details:
|
| Model NO.: | JC-PV 200 | Structure: | Horizontal |
|---|---|---|---|
| Transport Package: | Standard Export Wooden Case Package | Specification: | NMI-356 |
| Trademark: | Geekung | Origin: | China |
| HS Code: | 8477800000 | Production Capacity: | 1000 Sets/Year |
By using the theory of aerodynamic and centrifugal force, the Deflashing Machine for Rubber O Ring/Rubber Seal is developed to make the flash and rubber products separated, applicable to all silicone, rubber, nitrile rubber, fluorine rubber seals and other kinds of molded rubber parts, such as O-Ring, rubber plug, gasket,rubber particles,Y-ring,solid miscellaneous special shaped rubber parts (rubber OD:3-80mm,flash thickness less than 0.2mm,rubber parts with flash groove),a whole molded rubber product can be processed directly to remove its flash.
| Model | NMI-356 |
| Spin-chamber capacity | 18 Liter |
| Diameter of spin-chamber | 356mm |
| Max.spinning speed | 10000 RPM (adjustable) |
| Operation time/batch | Depends on different rubber parts, Cycle time adjustable |
| Motor | 4KW |
| Variable-frequency Drive | 5.5KW |
| Electronic control system | PLC+Touch screen control, automatic storage operating system. |
| Water spraying function | Automobile-grade automatic water spraying function. |
| Fresh air system: | Compressed air-cooling device |
| Transmission system | -Aviation grade aluminum V-ribbed pulley. -Automobile grade American gates conveyor belts. -High-speed bearings imported from Germany. |
| Working Noise | insulated for sound reduction |
| Dimension | L1330*W650*H900mm |
| Weight | 350 KGS |
| Model | NMI-406 |
| Dimension | L1450*W700*H1000mm |
| Spin-chamber capacity | 22 Liter |
| Diameter of spin-chamber | 406 mm |
| Max.spinning speed | 10000 RPM (adjustable) |
| Operation time/batch | Depends on different rubber parts, Cycle time is adjustable |
| Motor | 5KW |
| Variable-frequency Drive | 7.5KW |
| Electronic control system | PLC+Touch screen control, automatic storage operating system. |
| Water spraying function | Automobile-grade automatic water spraying function. |
| Fresh air system: | Compressed air-cooling device |
| Transmission system | -Aviation grade aluminum V-ribbed pulley. -Automobile grade American gates conveyor belts. -High-speed bearings imported from Germany. |
| Working Noise | insulated for sound reduction |
| Dimension | L1450*W700*H1000mm |
| Weight | 400 KGS |
| Application | Separation of burrs (unwanted flash) from the good rubber parts |
| Explosion-proof professional vibration motor | 0.18 KW |
| Spring cushion | Special spring rubber combined buffer device |
| Replaceable mesh screens | 10 PCS |
| Dimension | L1250*W600*H600mm |
| Weight | 100 KGS |
The spin trim type rubber deflashing machine is packaged well by the strong wooden cases,ensuring the machines non damage during the long distance of land and sea transportation, and reach the clients factories safely.
We supply quick after sales service, including online consultation,instruction and also onsite face-face service if required by the clients.
We have professtional after sales serivce team who can give you satisfactory quick response,including technical questions,trouble-shooting,installation,etc.
Our business principle is that :
Move ahead along with the spirit of "Responsibility& Sincerity for Customers" and "Cooperative&Enterprising Team" to "Create a Better Future Together ".
It is our promise and duty to execute the 3 No worries for clients:
No worries before order,
No worries after order,
No worries in produciton.
Tel: 86-025-52631617
