Upgrade Your Manufacturing Plant with High Productivity Rubber Gasket Cutter

Upgrade Your Manufacturing Plant with High Productivity Rubber Gasket Cutter

Upgrade Your Manufacturing Plant with High Productivity Rubber Gasket Cutter
Upgrade Your Manufacturing Plant with High Productivity Rubber Gasket Cutter Upgrade Your Manufacturing Plant with High Productivity Rubber Gasket Cutter Upgrade Your Manufacturing Plant with High Productivity Rubber Gasket Cutter Upgrade Your Manufacturing Plant with High Productivity Rubber Gasket Cutter Upgrade Your Manufacturing Plant with High Productivity Rubber Gasket Cutter

Large Image :  Upgrade Your Manufacturing Plant with High Productivity Rubber Gasket Cutter

Product Details:
Place of Origin: China
Brand Name: Mixer
Certification: CE
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $3,500.00 - $9,999.00/sets
Packaging Details: wooden case package
Delivery Time: 20-30days
Payment Terms: T/T
Supply Ability: 30sets per months

Upgrade Your Manufacturing Plant with High Productivity Rubber Gasket Cutter

Description
Condition: New Video Outgoing-inspection: Provided
Machinery Test Report: Provided Warranty Of Core Components: 2 Years
Core Components: PLC, Bearing, Motor Machine Type: Rubber Gasket Cutting Machine
Dimension(L*W*H): 1200x800x1210 Weight: 300
Warranty: 1 Year Key Selling Points: High Productivity
Showroom Location: Turkey, India, Poland Applicable Industries: Manufacturing Plant, Rubber&plastic Factory
After-sales Service Provided: Engineers Available To Service Machinery Overseas Marketing Type: Ordinary Product
Port: Shanghai

Product Description



Application:

Fast cut of all kinds of rubber, silicone gaskets/ washer, ring-shaped tubular products.

Features:

1. When the cut is finished, materials take off automatically, and through the collection boxes to gather the cut products.

2. Vacuum absorption of the cut product, so ensuring the finished product more precise.

3. Automatic air blowing function makes loading and unloading more convenient , greatly improve the product cutting efficiency;

4. Using color LCD touch screen control, operation is simple.

5. All electrical components, pneumatic components are imported from abroad or domestic famous brand products, to ensure long-term use, reliability and stability of the new machine.

6.  According to customer requirements, choose to install a round blade or strip blade, ensuring cost saving on the blade.

7.There are single shaft ,double shafts,4 shafts for options.

Specification



Model

JCM200-1

JCM200-2

cutting efficiency

≥60 times /min

≥60 times /min

Working rotation speed

0-3000rpm

0-3000rpm

Cut precision

≤±0.05 mm

≤±0.05 mm

                 Cut range

(1)     Rubber diameter:10-150mm

(2)Cut length (standard): 140mm; Lengthened type 350

(3)Rubber wall thickness: 18mm

(2)     Rubber diameter:10-150mm

(2)Cut length (standard): 140mm; Lengthened type 350

(3)Rubber wall thickness: 20mm

Specification of blade

1.Round disc blade:60*25.4x0.3

2.Strip shape 3x3x60mm

1.Round disc blade:60*25.4x0.3

2.Strip shape 3x3x60mm

consumption of compressed air

20L/min

30L/min

           Air pressure

0.5Mpa-0.8Mpa

0.5Mpa-0.8Mpa

Vacuum degree

≤-0.035Mpa

≤-0.035Mpa

               Power source

AC220V±5%

AC220V±5%

               Total power

1.4 KW

3 KW

Total weight

280kg

550kg

Dimension

1200×800×1210mm

1600×900×1650mm

Finished Products
