Product Details:
|
| Condition: | New | Voltage: | 220V/380V/440V |
|---|---|---|---|
| Dimension(L*W*H): | As According | Weight: | 14000 Kg |
| Warranty: | 1 Year | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Color: | Custom Made | Power: | 45KW |
| Port: | Shanghai |
Application: This machine is designed specially for precise calendaring and sheeting of material that contain high magnet or ferrous powder.
| Model | XK-Φ460×800B | XK-Φ550×1000B |
| Roll size(mm) | Φ460xL800 | Φ550xL1000 |
| Roll material | 42 chrome molybdenum(MC3),alloy forging roll, chrome platen thickness:0.25mm | 42 chrome molybdenum(MC3), alloy forgingroll, chrome platen thickness:0.25mm |
| Rear roll linear speed(m/min) | 0-18 (variable speed inventor control) | 0-16(DC CVT speed control) |
| Roll fraction ratio | 1:1.14 | 1:1.07 |
| Roll gap range (mm) | 0-8 | 0-10 |
| Sheeting width(mm) | ≤600 | ≤800 |
| Main Motor power (KW) | 45 (with variable speed inverter) | 90 (DC Motor) |
| Main gear reducer | single input and double output hardened gear reducer, with gear grinding duly machining. | single input and double output hardened gear reducer, with gear grinding duly machining. |
| Weight (Kg) | 14000 | 28000 |
