7.5kW Power and 320mm Roll Length XK-300 Lab Open Mill Two Roll Rubber Mixing Machine

7.5kW Power and 320mm Roll Length XK-300 Lab Open Mill Two Roll Rubber Mixing Machine
7.5kW Power and 320mm Roll Length XK-300 Lab Open Mill Two Roll Rubber Mixing Machine 7.5kW Power and 320mm Roll Length XK-300 Lab Open Mill Two Roll Rubber Mixing Machine 7.5kW Power and 320mm Roll Length XK-300 Lab Open Mill Two Roll Rubber Mixing Machine 7.5kW Power and 320mm Roll Length XK-300 Lab Open Mill Two Roll Rubber Mixing Machine 7.5kW Power and 320mm Roll Length XK-300 Lab Open Mill Two Roll Rubber Mixing Machine 7.5kW Power and 320mm Roll Length XK-300 Lab Open Mill Two Roll Rubber Mixing Machine

Large Image :  7.5kW Power and 320mm Roll Length XK-300 Lab Open Mill Two Roll Rubber Mixing Machine

Product Details:
Place of Origin: China
Brand Name: Mixer
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: $7,600.00/sets >=1 sets
Packaging Details: film wrap into container
Delivery Time: 60days
Payment Terms: T/T
Supply Ability: 60DAYS
Contact Now

7.5kW Power and 320mm Roll Length XK-300 Lab Open Mill Two Roll Rubber Mixing Machine

Description
Diameter Of Roll(mm): 160 Mm Length Of Roll(mm): 320 Mm
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Warranty Of Core Components: 5 Years Core Components: PLC, Engine, Bearing, Motor, Pressure Vessel, Gear
Cooling Mode: Water Cooling Condition: New
Voltage: As Per Customer's Request Dimension(L*W*H): 1650xW980xH1500mm
Warranty: 1 Year Key Selling Points: Sustainable
Power (kW): 7.5 Weight (KG): 1200 KG
Applicable Industries: Manufacturing Plant Showroom Location: Turkey
Max. Gap Between Rolls: 5mm Fraction Ratio Of Rolls: 1:1.27
Roll Heating & Cooling: Through Universal Rotary Joints With Internal Spray After Warranty Service: Video Technical Support







Product Description





Used for rubber&plastic mixing,sheeting.

Features:
· Tailored structure,stable performance, easy to operate.
· There are varied speeds and fraction ratios available, which can satisfy most customers’ formula and processing requirements.
· Frame, frame cap and base, looking very nice, are welded and treated by annealing for stress relieving.
· Chilled alloy cast iron roll is abrasion resistant with long service life.
· The speed reducer is the hard-tooth surface gear reducer of Class 6 precision, which has long service life and low noise.
· Perfect emergency stop device can ensure the safety of personnel and equipment.
· The seal structure with special design can eliminate the leaking phenomenon of lubricating oil.
· Stock pan is easy to clean up with dislodging device.
· Human nature designed operating system reduces labor intensity.
· Modular structure offers various structures for customers’ option.
· The flexible design system can satisfy customers’ special design requirements within the shortest time.
· A load test running will be made to the assembled equipment in our company to save debugging time for customers.





Specification

 HOT SALE XK-300 LAB OPEN MILL TWO ROLL RUBBER MIXING MACHINE/desktop tworoll open mixing mill









Shipment moment

 HOT SALE XK-300 LAB OPEN MILL TWO ROLL RUBBER MIXING MACHINE/desktop tworoll open mixing millHOT SALE XK-300 LAB OPEN MILL TWO ROLL RUBBER MIXING MACHINE/desktop tworoll open mixing millHOT SALE XK-300 LAB OPEN MILL TWO ROLL RUBBER MIXING MACHINE/desktop tworoll open mixing millHOT SALE XK-300 LAB OPEN MILL TWO ROLL RUBBER MIXING MACHINE/desktop tworoll open mixing mill









Customer visit

 HOT SALE XK-300 LAB OPEN MILL TWO ROLL RUBBER MIXING MACHINE/desktop tworoll open mixing millHOT SALE XK-300 LAB OPEN MILL TWO ROLL RUBBER MIXING MACHINE/desktop tworoll open mixing mill
