Product Details:
|
| Condition: | New | Machine Type: | Post Curing Oven |
|---|---|---|---|
| Voltage: | 380V | Dimension(L*W*H): | 1200x1520x1460 |
| Warranty: | 1 Year | Key Selling Points: | Accurate Temperature Control |
| Showroom Location: | Turkey | Applicable Industries: | Manufacturing Plant |
| After Warranty Service: | Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service | Local Service Location: | Turkey |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Port: | Shanghai |
It applies to secondary vulcanized silicone rubber, silicone mold curing, vulcanized silicone of food industry, curing molded medical silicone, silicone hose post curing, for baking, drying, finalizing formation.
Model | Working Chamber size (DxWxH:mm) | Working Chamber Volume: Liter | Working temperature range (℃) | Temperature uniformity (℃) | Total Power (KW) | Voltage | Overall Size (DxWxH:mm) |
XT-1 | 350x450x450 | 70L | RT~300 | ±2.5~3 | 2 | 220V | 550x970x900 |
XT-2 | 450x550x550 | 136L | RT~300 | ±2.5~3 | 3 | 220V | 650x1070x1000 |
XT-3 | 500x600x750 | 225L | RT~300 | ±2.5~3 | 4.5 | 380V | 700x1120x1200 |
XT-4 | 800x800x1000 | 640L | RT~300 | ±2.5~3 | 9 | 380V | 1000x1320x1460 |
XT-5 | 1000x1000x1000 | 1000L | RT~300 | ±2.5~3 | 12 | 380V | 1200x1520x1460 |
XT-6 | 1000x1200x1200 | 1440L | RT~300 | ±2.5~3 | 15 | 380V | 1200x1790x1980 |
XT-7 | 1000x1200x1500 | 1800L | RT~300 | ±2.5~3 | 18 | 380V | 1200x1790x2280 |
XT-8 | 1200x1500x1500 | 2700L | RT~300 | ±2.5~3 | 21 | 380V | 1400x2090x2280 |
More specifications can be made to order. | |||||||
