Product Details:
|
| Condition: | New | Machine Type: | Plate Vulcanizing Press |
|---|---|---|---|
| Voltage: | 380V | Dimension(L*W*H): | According To The Machine |
| Weight: | According To The Model | Warranty: | 1 Year After Shipment |
| Key Selling Points: | Long Service Life | Showroom Location: | Turkey |
| Applicable Industries: | Manufacturing Plant | After Warranty Service: | Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service |
| Local Service Location: | Turkey | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Press: | Rubber Vulcanizing Press | Rubber Mat: | Rubber Mat Vulcanizing Press |
| Port: | Shanghai |
Model | Clamping force (Ton) | Working Pressure (Mpa) | Plate size (mm) | Plates distance (mm) | Max. Stroke (mm) | Heating Power (KW) | Motor Power (KW) |
XLBD-25T | 25 | 16 | 300x300 | 100 | 250 | 4.8 | 3 |
XLBD-50T | 50 | 16 | 400x400 | 150 | 300 | 9 | 3 |
XLBD-63T | 63 | 16 | 500x500 | 150 | 300 | 12 | 4 |
XLBD-100T | 100 | 16 | 800x800 | 200 | 300 | 14 | 3 |
XLBD-160T | 160 | 16 | 750x850 | 125 | 600 | 16 | 3 |
XLBD-200T | 200 | 18 | 800x800 | 250 | 300 | 20 | 7.5 |
XLBD-315T | 315 | 18 | 1000x1000 | 250 | 300 | 24 | 11 |
XLBD-500T | 500 | 18 | 1100x1100 | 250 | 350 | 30 | 15 |
XLBD-630T | 630 | 18 | 1200x2000 | 300 | 350 | 35 | 15 |
XLBD-1000T | 1000 | 18 | 1200x1200 | 300 | 350 | 35 | 18.5 |
XLBD-1250T | 1250 | 18 | 1500x1200 | 300 | 400 | 40 | 18.5 |
